The Shacman X3000 6x4 10 Wheel Head Tractor Truck is a classic product of Shaanqi Heavy Duty Trucks, which is positioned in the middle and high-end logistics market, combining cost-effectiveness and high performance. Its appearance adopts the family design, with hard lines and a wide front face, equipped with chrome-plated decorations and large curved glass to enhance aerodynamic performance. The cab is designed with full floating suspension, and the interior is spacious and equipped with comfortable features such as air master seats and electronically controlled automatic climate control.
Shacman X3000 6x4 10 Wheel Head Tractor Truck are equipped with Weichai WP12 series engines, such as WP12.460E50 (460 hp) and WP13.550E501 (550 hp), which can meet the National 5 or National 6 emission standards, with strong power and good fuel economy. The transmission is matched with Faster 12JSD180TA or 12JSDX240TA, etc., which has high transmission efficiency and smooth gear change. The cab adopts extended flat roof or high roof design, with sufficient space and rich interior configuration to meet the comfort requirements of long-distance transport. In addition, the whole vehicle adopts lightweight design, high-strength frame and suspension system to ensure the carrying capacity, and the braking system is equipped with ABS and other safety devices to enhance driving safety.
MODEL |
SX42555U324 |
|
Driving type |
6*4,Left Hand Drive |
|
Curb weight |
8500/9200/9600/9800kg |
|
Overall Dimension |
6825×2490×(3155-3725)mm (technology) |
|
Wheelbase |
3175+1400mm |
|
Max. Speed |
110km/h |
|
Max. Grade ability |
30 |
|
Engine |
Model |
CUMINS &WECHAI |
Emission Standard |
EURO-2/3/5/6 |
|
Rated output power |
(340-560)HP@(1800-2200)rpm |
|
Max.Torque |
2000 (2400N.m transmission for engines over 430hp) |
|
Displacement |
8-13 |
|
Transmission |
FA-ST 12JSD200T+QH50PTO, Manual, 12F/2R |
|
Front axle |
MA-N 7.5/9.5T |
|
Rear axle |
MA-N 13/16t single/double-stage |
|
Clutch |
¢430 diaphragm clutch |
|
Steering |
Z-F technology, left hand drive |
|
Suspension |
multiple leaf springs front and rear, with rear stable bar |
|
Fuel tank |
600+300L aluminum alloy tank |
|
Wheels and tires |
12R22.5/12.00R20 |
|
ABS |
WA-BCO 4-ways ABS |
|
Cabin |
X3000 High roof cabin/two sleeping bed/ air -driver seat/ four-point hydraulic suspension cab/ A/C / metal bumper |
The engine displacement of the Shacman X3000 6x4 10 Wheel Head Tractor Truck ranges from 11.596L to 12.54L, and the maximum torque can reach 2,100N・m to 2,550N・m, with obvious characteristics of low speed and high torque output, and strong climbing and overtaking ability. The cab is equipped with a four-point air suspension system, which effectively reduces vibration and noise and provides a good driving experience. The frame and suspension system are made of high-strength steel to ensure the stability and durability of the truck under heavy load. The front and rear steel plate spring suspension and dual circuit pneumatic braking system, together with the large-capacity air storage cylinder, provide safe and reliable braking. The wiring harness of the whole truck is reasonably bundled and partially strengthened to reduce the risk of failure during operation. In addition, Shacman X3000 6x4 10 Wheel Head Tractor Truck is equipped with a large-capacity aluminium alloy fuel tank and gas tank, which has a strong range and reduces the number of refueling times, thus improving operational efficiency.
The Shacman X3000 6x4 10 Wheel Head Tractor Truck is suitable for long-distance high-speed logistics, coal transport, gravel transport and other scenarios. Its strong power and high carrying capacity can meet the transport needs of heavy-duty goods, ensuring that the goods are delivered to their destinations in a timely and safe manner. In long-distance and high-speed logistics, its low wind resistance design and fuel economy can significantly reduce operating costs. In coal and gravel transport, its high load capacity and stability ensure reliable operation under complex road conditions. In addition, Shacman X3000 6x4 10 Wheel Head Tractor Truck can also be used in special areas such as hazardous materials transport, with its regulatory requirements and safety devices to protect the transport of hazardous materials.
