As a leader in the field of logistics and transport, DERUN three-axle dropside semi trailers are tailor-made for efficient, heavy-duty and diversified transport needs. The overall design of the vehicle integrates modern automotive manufacturing technology and innovative design concepts, aiming to bring users an unprecedented transport experience.
Derun three-axle dropside semi trailer adopts three-axle structure design, which not only greatly improves the loading capacity, but also ensures the vehicle's driving stability and manoeuvrability under complicated road conditions. The railing design takes into full consideration the convenience of loading and unloading and the safety of fixing the goods, providing users with more flexible and efficient transport solutions.
1. Strong power, energy saving and environmental protection
DERUN three-axle dropside semi trailers are equipped with high-performance diesel engines with abundant power, which can meet the acceleration and hill climbing needs under different road conditions.
2. Sturdy structure, strong load-bearing capacity
The frame and rails made of high-strength steel are precision welded and strengthened to ensure the high load carrying capacity and durability under long-term use.
3. Flexible handling, safe and reliable
Equipped with advanced ABS anti-lock braking system and EBS electronic braking system, which greatly shortens the braking distance and improves the safety in emergency situations.
4. Convenient loading and unloading, efficient use
The railings are designed to be folded or quickly dismantled, so that the loading space can be flexibly adjusted according to the size of the goods, which is convenient for quick loading and unloading and improves the transport efficiency.
Side Wall Semi Tralier |
|
Size |
12500x2500x2800mm |
Payload |
60 ton |
Tare Weight |
8500kg |
Axle |
2/3/4 pcs, 13T16T,BPW/FUWA /DERUN |
Suspension |
Mechanical Suspension / air suspension / Bogie suspension (Germany Type or America Type ) |
Tire |
12R22.5, 12.00R20,315/80R22.5,12 pcs |
Wheel Rim |
8.25/9.0/8.0/8.5 |
King Pin |
2"/3.5" |
Main Beam |
Beam height 500 mm, Upper plate 14 mm, lower plate 16 mm: Middle plate 8 mm |
Leaf Spring |
90*13-10layer, 4/6/8 sets |
Landing Gear |
Standard 28Ton, JOST brand |
Platform |
3/4mm |
Side Wall/Board |
600/800/1000/1200mm |
Twist Lock |
12 pcs container lock |
Tool Box |
1 or more can be opentional |
Air Wiring |
doule air line ; |
Electricity Wiring |
6 core wiring; 24v or 12v ;LED lamp; |
Brake System |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber;Two 40L air tanks, ABS Optional |
Painting |
complete chassis sand blasting;electrophoresis coating;1 coat of anticorrosive prime; |
|
2 coats of final painting |
Accessories |
brake shoe;spare tire cranking;shaft head wrench;jack 50ton;tire bolt;lamp |
With its excellent performance and adaptability, DARUN three-axle railcars are widely used in many fields:
Logistics and warehousing: suitable for inter-city long-distance distribution of bulk goods
Agricultural production: for seasonal transport of crops and agricultural products
Infrastructure construction: involved in roads, bridges, water conservancy and other engineering projects for the transport of materials
Mining: It is suitable for short-distance transfer of heavy materials such as ore and coal from mining sites.
High-strength frame: adopts high-quality alloy steel and undergoes strict heat treatment to enhance the overall strength and anti-fatigue performance.
Intelligent management system: integrated GPS navigation, fuel consumption monitoring, fault diagnosis and other functions to achieve intelligent vehicle management.
Comfortable cab: ergonomic seats, automatic air-conditioning, multimedia entertainment system, creating a comfortable driving environment.
Diversified Configurations: Different lengths of compartments, different heights of rails and special cargo fixtures can be customised according to customers' needs.
